OAuth 2.0 and OIDC: The Difference and When to Use Each

The "Sign in with Google" Bug That Handed Over Every Account

A startup I consulted for shipped their login flow in a weekend. "Sign in with Google" worked. Users logged in, the app got back an access token from Google's token endpoint, and the backend called https://www.googleapis.com/oauth2/v1/tokeninfo to extract the user's email. Whichever email came back became the logged-in user. Elegant, right? It passed code review. It passed a security scan. It shipped.

Six months later a penetration tester demonstrated full account takeover in 90 seconds. The attack: register any third-party app with Google, trick a victim into granting it the email scope, harvest the resulting access token, and hand that token to the startup's backend. The backend dutifully called Google's tokeninfo endpoint, got back the victim's email, and logged the attacker in as the victim. The access token was never intended for this application -- but the app never checked.

This is "token confusion," the single most common failure mode when teams use OAuth 2.0 for what looks like login. OAuth 2.0 is an authorization framework. It tells you an app is allowed to do something. It does not reliably tell you who the user is. OpenID Connect (OIDC) solves this by issuing ID tokens with a verifiable aud (audience) claim that is bound to your client. If the startup had used OIDC instead of OAuth for login, the attacker's token would have failed the aud check immediately.

This guide is about avoiding that bug -- and the dozen other ways identity flows go sideways. You will click "Sign in with Google" hundreds of times this year. Understanding the two protocols underneath that button, where they overlap and where they diverge, is how you build login flows that do not end up in a breach post-mortem.

OAuth 2.0: Delegated Authorization

OAuth 2.0 is an authorization framework that lets a third-party application obtain limited access to a user's resources on another service, without exposing the user's credentials. It issues access tokens that define what the application can do, not who the user is. That distinction is the one I want burned into your memory -- it is the root cause of the token-confusion bug above.

OAuth 2.0 replaced OAuth 1.0's complicated signature scheme with bearer tokens over TLS. The core idea is simple: instead of giving an app your password, you grant it a token with specific permissions (scopes). The token expires, can be revoked, and limits damage if compromised. The part OAuth deliberately left out of scope was identity -- and that gap is exactly what OIDC was designed to fill.

OAuth 2.0 Grant Types

OAuth 2.0 defines several flows for obtaining tokens. Here's what matters in 2026:

1. Authorization Code Grant -- The standard for server-side web apps. The user authenticates with the authorization server, which redirects back with a short-lived code. Your backend exchanges that code for tokens. The user never sees the tokens.
2. Authorization Code + PKCE -- Required for single-page apps and mobile apps. PKCE (Proof Key for Code Exchange) adds a code verifier/challenge pair that prevents authorization code interception attacks. This replaced the Implicit flow.
3. Client Credentials -- Machine-to-machine communication with no user involved. Your service authenticates directly with the authorization server using a client ID and secret. Used for backend microservice calls.
4. Device Authorization Grant -- For devices without browsers (smart TVs, CLI tools). The device displays a code; the user enters it on a separate device with a browser.

Watch out: The Implicit Grant is deprecated. It returned tokens directly in the URL fragment, which exposed them to browser history and referrer headers. If you're still using it, migrate to Authorization Code + PKCE immediately.

Authorization Code Flow Step by Step

1. Your app redirects the user to the authorization server's /authorize endpoint with the requested scopes.
2. The user authenticates and consents to the requested permissions.
3. The authorization server redirects back to your redirect_uri with an authorization code.
4. Your backend sends the code, client ID, and client secret to the /token endpoint.
5. The authorization server returns an access token (and optionally a refresh token).
6. Your app uses the access token to call the resource server's API.

GET /authorize?
  response_type=code
  &client_id=your-client-id
  &redirect_uri=https://yourapp.com/callback
  &scope=read:profile
  &state=random-csrf-token
  &code_challenge=BASE64URL(SHA256(code_verifier))
  &code_challenge_method=S256

POST /token
Content-Type: application/x-www-form-urlencoded

grant_type=authorization_code
&code=AUTH_CODE_FROM_CALLBACK
&redirect_uri=https://yourapp.com/callback
&client_id=your-client-id
&client_secret=your-client-secret
&code_verifier=ORIGINAL_CODE_VERIFIER

What Is OpenID Connect (OIDC)?

Definition: OpenID Connect (OIDC) is an identity layer built on top of OAuth 2.0. It adds a standardized way to verify user identity by introducing ID tokens (JWTs containing user claims), a userinfo endpoint, and a discovery mechanism. OIDC answers "who is this user?" while OAuth answers "what can this app do?"

Before OIDC, developers abused OAuth 2.0 for authentication by calling a provider-specific API (like Facebook's /me endpoint) with an access token. Every provider did it differently. OIDC standardized this by defining exactly what an identity response looks like.

What OIDC Adds to OAuth 2.0

Feature	OAuth 2.0	OIDC
Purpose	Authorization (access to resources)	Authentication (identity verification)
Token type	Access token (opaque or JWT)	ID token (always JWT) + access token
User identity	Not standardized	Standard claims (sub, email, name, etc.)
Discovery	Not defined	/.well-known/openid-configuration
Userinfo endpoint	Provider-specific	Standardized /userinfo
Session management	Not defined	Optional spec for session tracking

The ID Token

The ID token is a JWT signed by the authorization server. It contains standard claims:

{
  "iss": "https://accounts.google.com",
  "sub": "110169484474386276334",
  "aud": "your-client-id",
  "exp": 1712345678,
  "iat": 1712342078,
  "nonce": "random-nonce-from-request",
  "email": "user@example.com",
  "email_verified": true,
  "name": "Jane Doe",
  "picture": "https://example.com/photo.jpg"
}

Your app validates the ID token by checking the signature against the provider's public keys (published at the JWKS URI), verifying the iss, aud, and exp claims, and confirming the nonce matches what you sent. If all checks pass, you know who the user is.

Standard Scopes and Claims

OIDC defines standard scopes that map to sets of claims:

• openid -- Required. Signals this is an OIDC request and triggers ID token issuance.
• profile -- Name, family name, picture, locale, updated_at.
• email -- Email address and whether it's verified.
• address -- Postal address.
• phone -- Phone number and whether it's verified.

PKCE: Why It Matters for Every Client

PKCE (pronounced "pixie") was originally designed for public clients that can't safely store a client secret -- mobile apps, SPAs, CLI tools. But as of OAuth 2.1, PKCE is recommended for all clients, including confidential ones.

Here's how it works:

1. Your app generates a random code_verifier (43-128 characters).
2. It computes code_challenge = BASE64URL(SHA256(code_verifier)).
3. The code challenge is sent with the authorization request.
4. When exchanging the code for tokens, the original code verifier is sent.
5. The authorization server hashes the verifier and compares it to the stored challenge.

This prevents an attacker who intercepts the authorization code from exchanging it for tokens -- they don't have the code verifier.

When to Use OAuth, OIDC, or Both

This is the question that trips up most teams. Here's a clear decision framework:

Scenario	Protocol	Why
Users log in to your app	OIDC	You need to know who the user is
Your app accesses a user's Google Calendar	OAuth 2.0 + OIDC	Identity for login, authorization for API access
Microservice-to-microservice calls	OAuth 2.0 (Client Credentials)	No user involved, just service identity
Third-party apps access your API	OAuth 2.0	Delegated access to resources
"Sign in with Google/GitHub" button	OIDC	Federated identity verification
API gateway token validation	OAuth 2.0 (token introspection or JWT)	Verifying access, not identity

Pro tip: If you're adding "Sign in with X" to your app, you always want OIDC. Pure OAuth 2.0 tells you the user granted access -- it doesn't reliably tell you who they are. The openid scope is what triggers the identity layer.

Costs and Provider Comparison

If you're not building your own authorization server, you'll use a managed identity provider. Here's how the major options compare in 2026:

Provider	Free Tier	Paid Starting At	Best For
Auth0 (Okta)	25,000 MAU	~$35/mo	Developer experience, extensive SDKs
AWS Cognito	50,000 MAU	$0.0055/MAU	AWS-native apps, cost efficiency at scale
Google Identity Platform	50,000 MAU	$0.0055/MAU	GCP-native, Firebase integration
Keycloak (self-hosted)	Unlimited (OSS)	Infra costs only	Full control, on-prem requirements
Clerk	10,000 MAU	$25/mo	Modern DX, pre-built UI components

A Correct OIDC Login Handler, Annotated

The token-confusion bug in the opener had a fix that fit in 30 lines. Here is what a production OIDC callback handler should actually do -- every step is a verification that prevents a specific attack class.

import { createRemoteJWKSet, jwtVerify } from 'jose';

const ISSUER = 'https://accounts.google.com';
const CLIENT_ID = process.env.OIDC_CLIENT_ID!;
const JWKS = createRemoteJWKSet(new URL(`${ISSUER}/jwks`));

export async function handleCallback(req: Request) {
  const url = new URL(req.url);
  const code = url.searchParams.get('code');
  const state = url.searchParams.get('state');

  // 1. CSRF protection: verify state matches the one in the session
  if (!state || state !== req.session.oauthState) {
    throw new Error('state mismatch -- possible CSRF');
  }

  // 2. Exchange code for tokens (PKCE verifier sent back here)
  const tokenRes = await fetch(`${ISSUER}/token`, {
    method: 'POST',
    body: new URLSearchParams({
      grant_type: 'authorization_code',
      code: code!,
      redirect_uri: process.env.OIDC_REDIRECT_URI!,
      client_id: CLIENT_ID,
      client_secret: process.env.OIDC_CLIENT_SECRET!,
      code_verifier: req.session.pkceVerifier,
    }),
  });
  const { id_token } = await tokenRes.json();

  // 3. Verify the ID token -- this is where token confusion gets caught
  const { payload } = await jwtVerify(id_token, JWKS, {
    issuer: ISSUER,       // must match the provider
    audience: CLIENT_ID,  // MUST be our client -- rejects tokens issued to other apps
  });

  // 4. Verify the nonce matches what we sent in the auth request
  if (payload.nonce !== req.session.oidcNonce) {
    throw new Error('nonce mismatch -- possible replay');
  }

  // 5. Only now is it safe to treat payload.sub as the user's identity
  return loginUser({ sub: payload.sub as string, email: payload.email as string });
}

Step 3 is the line that would have prevented the opener's breach. jwtVerify enforces aud === CLIENT_ID, so a token minted for any other application is rejected with a verification error. Do not skip it, do not disable audience checking "temporarily for testing," and do not trust an external tokeninfo endpoint to do this for you.

Common Mistakes and How to Avoid Them

Using Access Tokens for Authentication

An access token tells a resource server what the bearer is allowed to do. It doesn't reliably identify the user to your app. Access tokens can be issued to any client, and some providers issue opaque tokens with no user info. Always use the ID token for authentication.

Skipping State Parameter Validation

The state parameter prevents CSRF attacks on the callback endpoint. Generate a random value, store it in the session, and verify it when the callback arrives. Without it, an attacker can craft a URL that logs a victim into the attacker's account.

Not Validating ID Token Claims

You must verify the iss (issuer), aud (audience), exp (expiration), and nonce claims on every ID token. Libraries handle this, but misconfigured audience validation is a frequent source of token confusion attacks.

Frequently Asked Questions

Putting It Together

OAuth 2.0 and OIDC aren't competing protocols -- they're complementary layers. OAuth handles authorization, OIDC handles authentication, and most real-world applications need both. Start with OIDC for user login, add OAuth scopes when you need to access third-party APIs, and use Client Credentials for service-to-service calls. Pick a grant type based on your client type, always use PKCE, validate every token properly, and you'll avoid the security pitfalls that catch most teams.
