SSRF Attacks: What They Are and Why Cloud Environments Make Them Dangerous

Capital One, 106 Million Records, and a Single SSRF

On July 19, 2019 a former AWS engineer named Paige Thompson exploited a Server-Side Request Forgery (SSRF) vulnerability in a Capital One ModSecurity WAF rule. The attack was mechanically simple: she made the WAF send an HTTP request to 169.254.169.254 -- the EC2 instance metadata service -- and the response contained temporary IAM credentials for a role named *****-WAF-Role. Those credentials could s3:ListBucket and s3:GetObject across roughly 700 S3 buckets. She used them for four months, exfiltrating 106 million customer records, including 140,000 Social Security numbers and 80,000 bank account numbers.

The Department of Justice indictment, the 2022 conviction, and the $190 million class-action settlement all trace back to one unvalidated URL in a WAF filter. No kernel exploit, no zero-day, no supply chain compromise. SSRF plus cloud metadata is the highest-impact-per-line-of-code vulnerability in modern web applications, and the attack surface has only grown since 2019 as applications added more outbound HTTP features (webhook delivery, URL previews, PDF rendering, user-supplied image imports, LLM plugin tools).

This guide walks the full SSRF kill-chain, explains why IMDSv2 is necessary but not sufficient, and gives you a defensive checklist that would have stopped the Capital One breach before the first byte of data left the VPC.

The Capital One Kill Chain, Step by Step

1. Find the SSRF sink. The WAF had a feature that fetched URLs on behalf of rules -- intended to resolve remote RBL feeds. Attacker control over the URL parameter was the initial foothold.
2. Point at the metadata endpoint. http://169.254.169.254/latest/meta-data/iam/security-credentials/ returned the role name attached to the WAF's EC2 instance.
3. Read the temporary credentials. http://169.254.169.254/latest/meta-data/iam/security-credentials/*****-WAF-Role returned AccessKeyId, SecretAccessKey, and Token.
4. Use the credentials from anywhere. IAM does not care where API calls originate. aws s3 ls from the attacker's laptop worked exactly as it would from inside Capital One's VPC.
5. Enumerate and exfiltrate. s3:ListAllMyBuckets listed the targets. s3:GetObject pulled the data. No S3 bucket policy restricted which IPs could read with those credentials.

Every step was a defensive opportunity missed. IMDSv2 was not yet enforced. The IAM role had s3:* instead of a scoped-down list. The S3 buckets had no IP condition. The WAF had no URL validation for its own fetches. That is the real lesson: SSRF becomes a breach because defence in depth was absent at every layer, not because the initial bug was catastrophic on its own.

How SSRF Works: Step by Step

1. Find a server-side URL fetch. Any feature where your server fetches a URL based on user input is a potential SSRF vector: image imports, webhook delivery, URL previews, PDF rendering, file downloads.
2. Supply an internal URL. Instead of a legitimate external URL, the attacker provides a URL pointing to an internal resource: http://169.254.169.254/latest/meta-data/, http://localhost:6379/, or http://10.0.0.5:8080/admin.
3. The server makes the request. Because the request originates from your server (inside the network perimeter), firewalls and security groups allow it. The server sends the response back to the attacker.
4. Extract sensitive data. The attacker reads internal API responses, metadata credentials, configuration files, or anything else accessible from the server's network position.

# Vulnerable endpoint: fetches a URL and returns the content
@app.route('/preview')
def url_preview():
    url = request.args.get('url')
    # No validation -- attacker controls the URL
    response = requests.get(url)
    return response.text

# Attack: GET /preview?url=http://169.254.169.254/latest/meta-data/iam/security-credentials/my-role

The response contains temporary AWS credentials: AccessKeyId, SecretAccessKey, and Token. With these, the attacker can call AWS APIs as your EC2 instance's IAM role.

Definition sidebar: Server-Side Request Forgery (SSRF) is a vulnerability class where an attacker coerces a server into making HTTP (or other protocol) requests to destinations the attacker chooses. The server's network position -- inside the VPC, past the firewall, with IAM credentials available via metadata -- is the multiplier that turns a simple fetch feature into a cloud breach.

Why Cloud Environments Make SSRF Devastating

The EC2 Metadata Endpoint

Every EC2 instance has access to a link-local metadata service at 169.254.169.254. It exposes instance information, user data scripts, and -- critically -- IAM role credentials. The original Instance Metadata Service (IMDSv1) responds to simple GET requests with no authentication. Any process on the instance (or any SSRF vulnerability) can read these credentials.

# What an attacker gets from the metadata endpoint
curl http://169.254.169.254/latest/meta-data/iam/security-credentials/my-role

{
  "Code": "Success",
  "AccessKeyId": "ASIA...",
  "SecretAccessKey": "wJalr...",
  "Token": "FwoGZX...",
  "Expiration": "2026-04-07T18:00:00Z"
}

Beyond AWS: Other Cloud Metadata Services

Cloud Provider	Metadata Endpoint	What It Exposes
AWS EC2	169.254.169.254	IAM credentials, user data, instance info
GCP	metadata.google.internal (169.254.169.254)	Service account tokens, project metadata
Azure	169.254.169.254	Managed identity tokens, instance metadata
DigitalOcean	169.254.169.254	Droplet metadata, user data

Every major cloud uses the same IP address for metadata. SSRF is a cross-cloud problem.

IMDSv2: A Partial Mitigation

AWS introduced Instance Metadata Service v2 (IMDSv2) as a defense against SSRF. Instead of responding to simple GET requests, IMDSv2 requires a session token obtained via a PUT request with a custom header:

# IMDSv2: requires a PUT to get a session token first
TOKEN=$(curl -X PUT "http://169.254.169.254/latest/api/token" \
  -H "X-aws-ec2-metadata-token-ttl-seconds: 21600")

# Then use the token in subsequent requests
curl -H "X-aws-ec2-metadata-token: $TOKEN" \
  http://169.254.169.254/latest/meta-data/iam/security-credentials/my-role

This blocks basic SSRF attacks because most HTTP libraries follow redirects with GET requests and don't send custom headers. However, IMDSv2 isn't bulletproof:

• If the attacker can control the full HTTP request (method, headers), they can perform the PUT request.
• Some SSRF vulnerabilities allow arbitrary HTTP methods and headers (e.g., through SSRF in a proxy or HTTP client library).
• IMDSv2 is not enabled by default on all instance types. You must enforce it via launch templates or account-level settings.

Watch out: IMDSv2 is necessary but not sufficient. Enforce it across your account with aws ec2 modify-instance-metadata-options --http-tokens required, but don't treat it as a complete SSRF defense. You still need input validation and network controls.

SSRF Attack Variants

Basic SSRF

The server fetches the attacker-supplied URL and returns the response. The attacker can read internal resources directly.

Blind SSRF

The server makes the request but doesn't return the response to the attacker. The attacker infers information from response timing, status codes, or by directing the request to an attacker-controlled server that logs the incoming connection (with headers that may contain internal data).

SSRF via URL Parsing Discrepancies

Different URL parsers handle edge cases differently. An attacker might use:

• http://169.254.169.254 encoded as http://0xa9fea9fe (decimal to hex)
• http://2852039166 (decimal IP)
• http://[::ffff:169.254.169.254] (IPv6-mapped IPv4)
• http://169.254.169.254.nip.io (DNS rebinding)
• http://attacker.com@169.254.169.254 (URL authority confusion)

These bypass naive URL validation that only checks for the literal string 169.254.169.254.

How to Prevent SSRF

1. URL Validation with Allowlisting

The strongest defense is an allowlist of permitted domains or IP ranges. If your feature needs to fetch images from user-supplied URLs, restrict it to known image hosting domains. If it calls webhooks, validate against registered callback URLs.

from urllib.parse import urlparse
import ipaddress
import socket

ALLOWED_DOMAINS = {'images.unsplash.com', 'cdn.example.com'}
BLOCKED_RANGES = [
    ipaddress.ip_network('169.254.0.0/16'),   # Link-local
    ipaddress.ip_network('10.0.0.0/8'),        # Private
    ipaddress.ip_network('172.16.0.0/12'),     # Private
    ipaddress.ip_network('192.168.0.0/16'),    # Private
    ipaddress.ip_network('127.0.0.0/8'),       # Loopback
]

def is_url_safe(url: str) -> bool:
    parsed = urlparse(url)

    # Check scheme
    if parsed.scheme not in ('http', 'https'):
        return False

    # Check domain allowlist
    if parsed.hostname not in ALLOWED_DOMAINS:
        return False

    # Resolve DNS and check IP against blocked ranges
    try:
        ip = ipaddress.ip_address(socket.gethostbyname(parsed.hostname))
        for blocked in BLOCKED_RANGES:
            if ip in blocked:
                return False
    except (socket.gaierror, ValueError):
        return False

    return True

Pro tip: Always resolve the hostname to an IP and validate the IP against blocked ranges. Validating only the hostname is insufficient because DNS rebinding attacks can make a domain resolve to an internal IP between your validation check and the actual request.

2. Enforce IMDSv2 on All EC2 Instances

# Enforce IMDSv2 at instance launch
aws ec2 run-instances \
  --metadata-options "HttpTokens=required,HttpPutResponseHopLimit=1"

# Enforce for existing instances
aws ec2 modify-instance-metadata-options \
  --instance-id i-1234567890abcdef0 \
  --http-tokens required \
  --http-put-response-hop-limit 1

Setting HttpPutResponseHopLimit=1 prevents containers running on the instance from reaching the metadata service through the host's network stack.

3. Network-Level Egress Controls

Restrict what your application servers can reach on the network:

• Block outbound traffic to 169.254.169.254 via iptables, security groups, or network policies.
• Use an egress proxy that enforces URL allowlists for all outbound HTTP requests.
• In Kubernetes, use NetworkPolicies to restrict pod egress to specific CIDR ranges.

4. Disable Unnecessary URL Fetching

If a feature doesn't need to fetch arbitrary URLs, don't build it that way. Instead of letting users provide URLs for profile images, have them upload files directly. Instead of server-side URL previews, use client-side rendering.

SSRF Testing Tools and Costs

Tool	Type	Cost	SSRF Detection
Burp Suite Pro	Web scanner	$449/yr	Collaborator for blind SSRF detection
OWASP ZAP	Web scanner (OSS)	Free	Active scan rules for SSRF
Nuclei	Vulnerability scanner (OSS)	Free	SSRF-specific templates
SSRFmap	SSRF exploitation (OSS)	Free	Automated SSRF exploitation and escalation
Snyk	SAST/DAST	Free tier available	Static analysis for SSRF patterns in code

Frequently Asked Questions

Defense in Depth Is Non-Negotiable

SSRF is a problem that demands layered defenses because no single control is sufficient. Validate URLs with allowlists and IP range checks. Enforce IMDSv2 with a hop limit of 1. Block metadata IP ranges at the network level. Minimize server-side URL fetching features. Monitor outbound traffic for anomalous connections to internal IPs. The organizations that get breached via SSRF aren't the ones without any defenses -- they're the ones relying on a single layer that an attacker found a way around.
